Shenzhen HuaXunNeng Technology Co.,Ltd

Products > Laptop adapter > For Dell > 19.5V 7.7A 7.4X5.0
Product name : 19.5V 7.7A 7.4X5.0
Item : 2015820145916
自定义参数 :
自定义参数 :
 Enlarge Image                   Back
             [Next Product]→


Details:

Technical Specifications:

AC input voltage ……120VAC
 Input frequency ………60Hz
 AC inrush current(max.) …….20A/230V
 4Line regulation (full load).......±0.5%
 Peak- to -peak ripple …….<100MV 7 Working temperature………….0-35℃-100% ,50℃-70% load
 Setup rise hold up time………100ms,50ms,20ms-240VAC  input
Strong made totally compatible part
 Over voltage protection………115%-135% rated output voltage
Withstand voltage………I/P-O/P 3Kvac,1 minute
Over load protection ………115%-135%fold back current limiting, Auto-recovery



Compatible with Models and Part P/N Reference Chart:

Dell Extra Slim 19.5V 7.7A 150W
Dell N3834 or D2746   Dell  / Delta :  PA-5M10, PA1151-06D, ADP-150EB, ADP-150RB B ,PA-15 ,PA-5M10 , J408p ,DA150PM100-00,R940P,PA-5M10,ADP-150RB B, 330-5829, 330-5830, ADP-150RB B
DELL 310-4180,310-6580, 310-7848, 310-7849, 330-5829,330-5830 R940P, 330-5830 R940P
